40 Ton Offset Pintle Hook 4-Hole Pattern, ringfeder interchange

40 Ton Offset Pintle Hook, 4-Hole Pattern, Ringfeder interchange

MAKE: Wallace Forge
MODEL: 2060115-R
DETAILS: 4 Bolt Pintle eye
CAPACITY: 40T
VERT: 9T
MOUNTING: Vehicle Side
DVALUE: 100kN
LATCH: 27T

FURTHER INFORMATION:

·          Rigid type pintle hook

-       Black Powder Coat Finish

·         Reduce capacity by 25% for off road applications and use with swivel type trailer drawbar.

·         M.G.T.W.: 90,000lbs.

·         M.V.L.: 18,000lbs.

will Interchange to ringfeder bolt pattern.

These pintle hooks are to be used with a drawbar with a 2 3/8" to 3" diameter eye and a ring thickness 1 1/4 to 1 5/8". The mounting plate should be at least 7/8" thick.
