Towbar to suit Auto Pin Coupling (Ringfeder) 50mm BT1700A-30T (inside chassis mount) including bolt kit

MODEL: BT1700A-30T

DETAILS: Towbar for Auto Pin Coupling (Ringfeder) to suit Heavy Duty Trucks to 30,000kg

APPLICATION: Heavy Rigid Truck

COUPLING: 50mm Auto Pin Coupling only

MAXIMUM ATM: 30,000kg standard

UPGRADEABLE: no but 21,000kg is available as standard

CHASSIS MOUNT: inside

INCLUDED: Towbar, bolt kits, mounting instructions, compliance plate once complete. 50mm Ringfeder sold separately.

For applications where the truck chassis is terminated close to the vehicle suspension, axle or brake components. Eg. Heavy tip trucks or trucks mounted with specialised machinery.

INSTALLATION: Drilling and bolting required for truck chassis and sideplates. Welding required for fixing crossmember, gussets and accessory components.

Comprehensive installation Instructions are provided to assist with ADR62 assurance and VSB6 compliance. Some applications require customised sideplates - consult with Bartlett if unsure.

* AS2213 automatic pin couplings (Ringfeder® etc.) (Ø 20 mm Holes, 160mm X 100mm - Ø 95mm centre hole).

Our range consists of the following:

TOW BAR - 50mm Ball & Pintle Hooks
Part #:	To suit coupling:	Application	Max ATM (kg):	Chassis Mount
BT350-3.5T	50mm Ball	Light/Medium Truck	3500	OUTSIDE
BT1250H-7T	Light Pintle hook + Receiver ball and mount for 50mm ball	Light/Medium Truck	7000kg Pintle / 3500kg Ball	OUTSIDE
BT1200H-7T	Light Pintle Hooks	Small/Medium Truck	7000	OUTSIDE
BT1300H-15T	Medium Pintle Hooks	Medium/Heavy Truck	15000	OUTSIDE
BT1400H-21.5T	Heavy Duty Pintle Hook - 6 Bolt (PH300)	Heavy Rigid Trucks	21500	OUTSIDE
BT1400H-30T	Heavy Duty Pintle Hook - 6 Bolt (PH300)		30000	OUTSIDE
TOW BAR - Bartlett Ball
Part #:	To suit coupling:	Application	Max ATM (kg):	Chassis Mount
BT1200B-7T	Bartlett 95 mm Ball	Medium Truck	7000	OUTSIDE
BT1300B-13T	Bartlett 127mm Ball	Medium/Heavy Truck	13000	OUTSIDE
BT1400B-21.5T	Bartlett 127mm Ball	Heavy Rigid Trucks	21500	OUTSIDE
BT1400B-30T	Bartlett 127mm Ball		30000	OUTSIDE
BT1700B-21.5T	Barttlett 127mm Ball	Heavy Truck	21500	INSIDE
BT1700B-30T	Barttlett 127mm Ball		30000	INSIDE
TOW BAR - Automatic Pin
Part #:	To suit coupling:	Application	Max ATM (kg):	Chassis Mount
BT1300A-17T	Automatic Pin and *some* Pintle Hooks	Medium/Heavy Truck	17000	OUTSIDE
BT1400A-21.5T	Automatic Pin	Heavy Rigid Trucks	21500	OUTSIDE
BT1400A-30T	Automatic Pin		30000	OUTSIDE
BT1700A-21.5T	Automatic Pin and *some* Pintle Hooks	Heavy Truck	21500	INSIDE
BT1700A-30T	Automatic Pin and *some* Pintle Hooks		30000	INSIDE
MULTI COUPLING
Part #:	To suit coupling:	Application	Max ATM (kg):	Chassis Mount
BT620-4.5T	62mm Square Solid Mount with 50mm Ball / Light Pintle Hook / 95mm Barlett Ball	Light/Medium Truck	4500	OUTSIDE
BT750-7T	75mm Square Solid Mount with 50mm Ball / Light Pintle Hook / 95mm Barlett Ball	Light/Medium Truck	7000	OUTSIDE

(BAR-BT1700A-30T-1)

SKU	BAR-BT1700A-30T-1
Brand	Bartlett
Shipping Weight	100.0000kg
Shipping Width	0.600m
Shipping Height	1.100m
Shipping Length	0.600m
Shipping Cubic	0.396000000m3
Unit Of Measure	ea
