Tow Hitch to suit 127mm Bartlett Ball to 21,500kg Truck Trailer Tow bar-INSIDE BT1700B-21.5T
More infoMake 4 interest-free payments of $1,678.84 fortnightly and receive your order now.
In StockTowbar to suit Bartlett Ball 127mm BT1700B-21.5T (inside chassis mounted)
MODEL: BT1700B-21.5T
DETAILS: Towbar for 127mm Bartlett Ball to suit Heavy Duty Trucks to 21,500kg
APPLICATION: Heavy Rigid Truck
COUPLING: 127mm Bartlett Ball only
MAXIMUM ATM: 21,500kg
UPGRADEABLE: yes to 30,000kg
CHASSIS MOUNT: inside
INCLUDED: Towbar, bolt kit, mounting instructions, compliance plate once complete. 127mm Bartlett Ball sold separately.
For applications where the truck chassis is terminated close to the vehicle suspension, axle or brake components. Eg. Heavy tip trucks or trucks mounted with specialised machinery.
INSTALLATION: Drilling and bolting required for truck chassis and sideplates. Welding required for fixing crossmember, gussets and accessory components.
Comprehensive installation Instructions are provided to assist with ADR62 assurance and VSB6 compliance. Some applications require customised sideplates - consult with Bartlett if unsure.
* AS2213 automatic pin couplings (Ringfeder® etc.) (Ø 20 mm Holes, 160mm X 100mm - Ø 95mm centre hole). ** Upgradeable to 30 000 kg
Our range consists of the following:
|
TOW BAR - 50mm Ball & Pintle Hooks |
|
|
||
|
Part #: |
To suit coupling: |
Application |
Max ATM (kg): |
Chassis Mount |
|
TBR350001-3.5T |
50mm Ball |
Light/Medium Truck |
3500 |
OUTSIDE |
|
TBR1250H0001-7T |
Light Pintle hook + Receiver ball and mount for 50mm ball |
Light/Medium Truck |
7000kg Pintle / 3500kg Ball |
OUTSIDE |
|
TBR1200H0001-7T |
Light Pintle Hooks |
Small/Medium Truck |
7000 |
OUTSIDE |
|
TBR1300H001-15T |
Medium Pintle Hooks |
Medium/Heavy Truck |
15000 |
OUTSIDE |
|
TBR1400H0001-21.5T |
Heavy Duty Pintle Hook - 6 Bolt (PH300) |
Heavy Rigid Trucks |
21500 |
OUTSIDE |
|
TBR1400H0002-30T |
|
30000 |
OUTSIDE |
|
|
TOW BAR - Bartlett Ball |
|
|
|
|
|
Part #: |
To suit coupling: |
Application |
Max ATM (kg): |
Chassis Mount |
|
TBR1200B0001-7T |
Bartlett 95 mm Ball |
Medium Truck |
7000 |
OUTSIDE |
|
TBR1300B0001-13T |
Bartlett 127mm Ball |
Medium/Heavy Truck |
13000 |
OUTSIDE |
|
TBR1400B0001-21.5T |
Bartlett 127mm Ball |
Heavy Rigid Trucks |
21500 |
OUTSIDE |
|
TBR1400B0002-30T |
|
30000 |
OUTSIDE |
|
|
TBR1700B0001-21.5T |
Barttlett 127mm Ball |
Heavy Truck |
21500 |
INSIDE |
|
TBR1700B0010-30T |
|
30000 |
INSIDE |
|
|
TOW BAR - Automatic Pin |
|
|
|
|
|
Part #: |
To suit coupling: |
Application |
Max ATM (kg): |
Chassis Mount |
|
TBR1300A0001-17T |
Automatic Pin and some Pintle Hooks |
Medium/Heavy Truck |
17000 |
OUTSIDE |
|
TBR1400A0001-21.5T |
Automatic Pin |
Heavy Rigid Trucks |
21500 |
OUTSIDE |
|
TBR1400A0002-30T |
|
30000 |
OUTSIDE |
|
|
TBR1700A0001-21.5T |
Automatic Pin and some Pintle Hooks |
Heavy Truck |
21500 |
INSIDE |
|
TBR-1700A0010-30T |
|
30000 |
INSIDE |
|
|
MULTI COUPLING |
|
|
|
|
|
Part #: |
To suit coupling: |
Application |
Max ATM (kg): |
Chassis Mount |
|
TBR620001-4.5T |
62mm Square Solid Mount with 50mm Ball / Light Pintle Hook / 95mm Barlett Ball |
Light/Medium Truck |
4500 |
OUTSIDE |
|
TBR7500001-7T |
75mm Square Solid Mount with 50mm Ball / Light Pintle Hook / 95mm Barlett Ball |
Light/Medium Truck |
7000 |
OUTSIDE |
(BAR-BT1700B-21-5T-2)
| SKU | BAR-BT1700B-21-5T-2 |
| Brand | Bartlett |
| Shipping Weight | 110.0000kg |
| Shipping Width | 0.600m |
| Shipping Height | 1.100m |
| Shipping Length | 0.600m |
| Shipping Cubic | 0.396000000m3 |
| Unit Of Measure | ea |
